Delta Cera 40

The Delta Cera 40 is a LDM 3D printer that is compatible with kaolin, gres, porcelain, TC-400 clay and earthenware. It is designed and manufactured in India. It is fitted with a lead screw extrusion that comes with a Nema 17 motor.

Download Brochure
Get Price Now

Major Features

Superior quality build
Emergency stop
Touchscreen
Material compatibility
Material storage
2
3
ceramic-3d1

Robust and stable mechanical build structure. Superior quality material used. Durable and reliable machine.

The printing area is within an enclosure to trap heat and block any drafts during print. The enclosure is an all aluminium canister.

The Delta Cera 40 has a larger printing area that can build larger volumes than the Delta Cera 30 printer. It has a 200ml piston volume machined ABS.

This ceramic printer is compatible with different materials. It can be loaded with up to 2kg of a chosen material.

The fully enclosed ceramic printer comes with an emergency stop safety feature. Avert any risk or hazards that could occur during print.

Delta Cera 40 Technical Specification

Column 1 Column 2
  • Nozzle diameter:
  • Printing area:
  • Material flow:
  • Motor attachment:
  • Pushing type:
  • Material piston volume：
  • Outer piston dimension:
  • Inner piston dimension:
  • Material load:
  • Material type:
  • Display:
  • 1.5, 2.5, 3.0, 4.0 mm
  • 380mm (d) x 600mm(H)
  • 2.5kg/hr (2.5 mm Nozzle)
  • Nema 17
  • Lead screw
  • 200ml
  • 35mm diameter
  • 31mm diameter
  • 2Kg
  • Filament loading cartridge
  • Touchscreen
Column 1 Column 2
  • Input power:
  • Output power:
  • Printing Speed:
  • Printing Speed Adjustment:
  • Pressure control system:
  • Printing Pressure:
  • Printing bed:
  • Safety feature:
  • Offline printing:
  • 220V 1.5A
  • 24V 15A
  • 40mm/sec
  • Yes
  • Yes
  • 6-18 bar
  • Wood
  • Emergency stop
  • Supported
Column 1 Column 2
  • Slicing software:
  • Supported OS:
  • Supported Files:
  • File Transfer:
  • CURA , Simplify3D
  • XP, Vista, Win7, Win8, LINUX, IOS
  • STL, OBJ, GCode
  • SD card
Column 1 Column 2
  • Training:
  • Warranty
  • Material:
  • Installation:
  • Our Support:
  • We provide training online or in person (on request).
  • 1 year warranty for the printer
  • Setup and installation (on request)
  • The printer comes with 2kg of a chosen material
  • Technical support by our experienced and dedicated Engineers, detailed manuals, online resources and much more will be provided.

Delta Cera 40 Technical Specification

  • Nozzle diameter:1.5, 2.5, 3.0, 4.0 mm

  • Printing area: 380mm (d) x 600mm(H)

  • Material flow: 2.5kg/hr (2.5 mm Nozzle)

  • Motor attachment: Nema 17

  • Motor attachment: Nema 17

  • Pushing type: Lead screw

  • Material piston volume：200ml

  • Outer piston dimension: 35mm diameter

  • Inner piston dimension: 31mm diameter

  • Material load: 2kg

  • Material type:Filament loading cartridge

  • Display: Touchscreen

  • Input power: 220V 1.5A

  • Output power: 24V 15A

  • Printing Speed: 40mm/sec (adjustable)

  • Printing Speed Adjustment: Yes

  • Pressure control system: Yes

  • Printing Pressure: 6-18 bar

  • Printing bed: Wood

  • Safety feature: Emergency stop

  • Offline printing: Supported

  • Slicing software:  CURA , Simplify3D

  • Supported OS: XP, Vista, Win7, Win8, LINUX, IOS

  • Supported Files: STL, OBJ, GCode

  • File Transfer: SD card

  • Training: We provide training online or in person (on request).
  • Warranty period: 1 year warranty for the printer
  • Installation: Setup and installation (on request)
  • Material: The printer comes with 2kg of a chosen material

  • Support: Technical support by our experienced and dedicated Engineers, detailed manuals, online resources and much more will be provided.
