OMEGA, The Dual Extrusion Workhorse 3D

OMEGA 3D printer is supported by the E3D dual extrusion all metal Chimera+ hotend, which enables printing of complex materials such as ABS, NYLON, PLA+ and even carbon fiber composites. The dual extruders double your productivity and reduce a significant amount of time to print your component/object.

Download Brochure
Get Price Now

Major Features

Dual Extruder
 Printing with Complex materials
Build volume
Reliable and robust components
Hotbed
1
5
6
einstein

You can mix and match material with the Omega 3D printer that supports two-filaments to print the same model. Alternatively, the second nozzle can be used to print water soluble support structures.

The Omega encompasses a large build up to a height of 320mm, width of 250mm and a height of 320mm for all your 3D printing needs.  Print multiple parts on Omega 3D printer with ease! You can print up to a height of 600 mm, with a diameter of 350mm.

The Omega printer is built using high quality shafts, lead screw and other machined components from MISUMI.

Omega 3D printer is powered by original Makerbase controller boards and comes integrated with a touch screen display. Using a 3D printer could never get any easier.

The motors used on Omega 3D printers are custom made with a longer body than other 3D printers. This ensures longer printing hours with better torque and less heat generated.

Omega Technical Specification

Column 1 Column 2
  • Machine dimensions :
  • Packaging Dimensions :
  • Build area:
  • Minimum print layer thickness:
  • Nozzle diameter:
  • Material Diameter :
  • Feeder type:
  • Display:
  • Hot bed:
  • 422.5 * 422.5 * 578mm
  • 440 * 540 * 610mm
  • 300 * 250 * 320mm
  • 20 microns
  • 0.4 mm (0.3 , 0.1 optional)
  • 1.75mm
  • Filament Fed
  •   Touchscreen
  • nano-glass hot bed
Column 1 Column 2
  • Maximum working speed:
  • Maximum print speed:
  • Maximum extrusion temperature:
  • Maximum hot bed temperature:
  • Maximum feeding speed:
  • 250 mm/sec
  • 100 mm/sec
  • 300°
  • 120°
  • 100 mm/s
Column 1 Column 2
  • Open source software:
  • Supported OS:
  • Supported Files:
  • Offline Printing:
  • Plug-in integration:
  • Cura
  • Windows, MacOS and Linux
  • STL, OBJ, GCode
  • Supported
  • Wifi, SD card & USB
Column 1 Column 2
  • Training:
  • Warranty
  • Our Support:
  • We provide training online or in person (on request).
  • 1 year warranty for the printer
  • Technical support by our experienced and dedicated Engineers, detailed manuals, online resources and much more will be provided.

Omega Technical Specification

  • Machine dimensions: 422.5 * 422.5 * 578mm
  • Packaging Dimensions: 440 * 540 * 610mm
  • Build area: 300 * 250 * 320mm
  • Minimum print layer thickness: 20 microns
  • Nozzle diameter: 0.4 mm (0.3 , 0.1 optional)
    (Original e3d Chimera+ Dual Hot-end)
  • Material Diameter: 1.75mm
  • Feeder type : Filament Fed
  • Display: Touchscreen
  • Hot bed: nano-glass hot bed
  • Maximum working speed: 250 mm/sec
  • Maximum print speed: 100 mm/sec
  • Maximum extrusion temperature: 300°
  • Maximum hot bed temperature: 120°

  • Maximum feeding speed: 100 mm/s

  • Open source software: Cura

  • Supported OS: Windows, MacOS and Linux

  • Supported Files: STL, OBJ, GCode

  • Offline Printing: Supported

  • Plug-in integration: Wifi, SD card & USB
  • Training: We provide training online or in person (on request).
  • Warranty period: 1 year warranty for the printer
  • Support: Technical support by our experienced and dedicated Engineers, detailed manuals, online resources and much more will be provided.
