Major Features
Made in India
Superior quality build
Special Cut material adhesion plate
Touchscreen
Nema 17 motor
This ceramic 3D printer is built with superior quality material. Robust and stable delta build structure. High quality 80/20 3030 aluminium extrusion making it corrosion resistant.
The Delta Cera 30 is installed with a machine cut extrusion piston and comes with ½ inch outlets for material extrusion. It is also fitted with a loading stand that can also store the material.
The printer speed settings can be adjusted depending on the project requirements. The printer is fitted with a dynamic pressure reducer valve, safety valve and pressure preventing valve.
The printer is compatible with TC-400 Clay, kaolin, porcelain, Gres and earthenware.
- Delta Cera 30 is equipped with additional features such as 2HP air compressor, 25 litre material tank and pressure settings between 6-12 bar.
- The cartridge is water resistant and can be immersed in a water bath.
- Fitted with special cut material adhesion plates
Delta Cera 30 Technical Specification
| Column 1 | Column 2 |
|---|---|
|
|
| Column 1 | Column 2 |
|---|---|
|
|
| Column 1 | Column 2 |
|---|---|
|
|
| Column 1 | Column 2 |
|---|---|
|
|
Delta Cera 30 Technical Specification
- Nozzle diameter: 2.5, 3.0 and 4.0 mm microns
- Printing area: 300mm (d) x 470mm(H)
- Clamps: 2 metal locks
- Inlet diameter: 6 mm
- Motor attachment: Nema 17
- Pushing type: Lead screw
Material piston volume：200ml
Outer piston dimension: 35mm diameter
- Inner piston dimension: 31mm diameter
Material piston inlet: 3mm diameter
Material piston outlet：4mm diameter
- Material load: 1kg
Material type:Filament loading cartridge
Display: Touchscreen
Movement type: Original HWIN Linear guides
- Input power: 220V 1.5A
Output power: 24V 15A
- Maximum extrusion temperature: 300°
Printing Speed: 60mm/sec (adjustable)
- Pressure reducer: Dynamic pressure reducer valve
- Safety valve: Yes
Pressure Preventing valve: yes
Printing Pressure: 6-9 bar
Printing bed: Wood (Special cut material adhesion plate)
Offline printing: Supported
Slicing software: Compatible with all slicing software (SLic3r)
Supported OS: Windows, MacOS and Linux
Supported Files: STL, OBJ, GCode
File Transfer: Wifi, SD card & USB
- Training: We provide training online or in person (on request).
- Warranty period: 1 year warranty for the printer
- Installation: Setup and installation (on request)
- Material: The printer comes with 2kg of a chosen material
- Support: Technical support by our experienced and dedicated Engineers, detailed manuals, online resources and much more will be provided.
